Specifications	RPR 4830-440R	RPR 4830-530R	RPR 4830-536R	RPR 4830-538R	RPR 4830-540R	RPR 4830-630R	RPR 4830-636F	RPR 4830-636R	RPR 4830-638F	RPR 4830-640F	RPR 4830-730F	RPR 4830-730R	RPR 4830-736F	RPR 4830-738F	RPR 4830-740F	RPR 4830-830F	RPR 4830-836F	RPR 4830-838F	RPR 4830-840F	RPR 4830-930F
Working width (m)	4	3,8	4,6	4,8	5	4,6	5,4	5,4	5,8	6,1	5,3	5,3	6,4	6,7	7	6,1	7,3	7,7	8,1	6,8
Working width (feet)	13′ 4″	12′ 6″	15′	15′ 10″	16′ 8″	15′	18′	18′	19′	20′	17′ 6″	17′ 6″	21′	22′ 2″	23′ 4″	20′	24′	25′ 4″	26′ 8″	22′ 6″
Number of coulters	4	5	5	5	5	6	6	6	6	6	7	7	7	7	7	8	8	8	8	9
Coulter size (cm)	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88	55.88
Coulter size (in)	22″	22″	22″	22″	22″	22″	22″	22″	22″	22″	22″	22″	22″	22″	22″	22″	22″	22″	22″	22″
Number of wheels	2	2	2	2	2	2	2	2	2	2	2	2	2	2	2	2	2	2	2	2
Number of Shanks	4	5	5	5	5	6	6	6	6	6	7	7	7	7	7	8	8	8	8	9
Shanks spacing (cm)	101	76	91	96	101	76	91	91	96	101	76	76	91	101	101	76	91	96	101	76
Shanks spacing (in)	40″	30″	36″	38″	40″	30″	36″	36″	38″	40″	30″	30″	36″	38″	40″	30″	36″	38″	40″	30″
Transport width (m)	3.4	3.4	4.3	4.3	4.3	4.3	3.5	4.9	3.5	3.5	3.5	4.9	3.5	3.5	3.5	3.5	4.4	4.4	4.4	4.4
Transport width (feet)	11′ 1″	11′ 1″	14′ 3″	14′ 3″	14′ 3″	14′ 3″	11′ 5″	15′ 11″	11′ 5″	11′ 5″	11′ 5″	15′ 11″	11′ 5″	11′ 5″	11′ 5″	11′ 5″	14′ 5″	14′ 5″	14′ 5″	14′ 5″
Number of sections	1	1	1	1	1	1	3	1	3	3	3	1	3	3	3	3	3	3	3	3
Frame type	Rigid	Rigid	Rigid	Rigid	Rigid	Rigid	Folding	Rigid	Folding	Folding	Folding	Rigid	Folding	Folding	Folding	Folding	Folding	Folding	Folding	Folding
Weight (kg)	between 1084 and 1447	between 1206 and 1660	between 1365 and 1819	between 1365 and 1819	between 1365 and 1819	between 1489 and 2031	between 1676 and 2220	between 1514 and 2059	between 1780 and 2324	between 1780 and 2324	between 1798 and 2433	between 1636 and 2271	between 1950 and 2585	between 1950 and 2585	between 1950 and 2585	between 2024 and 2750	between 2261 and 2986	between 2261 and 2986	between 2261 and 2986	between 2335 and 3151
Weight (lb)	between 2391 and 3191	between 2660 and 3660	between 3010 and 4010	between 3010 and 4010	between 3010 and 4010	between 3279 and 4479	between 3695 and 4895	between 3339 and 4539	between 3925 and 5125	between 3925 and 5125	between 3964 and 5364	between 3608 and 5008	between 4300 and 5700	between 4300 and 5700	between 4300 and 5700	between 4463 and 6063	between 4984 and 6584	between 4984 and 6584	between 4984 and 6584	between 5147 and 6947
Minimum working depth (cm)	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3	20.3
Maximum working depth (cm)	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6	40.6
Working depth (min.) (inches)	8″	8″	8″	8″	8″	8″	8″	8″	8″	8″	8″	8″	8″	8″	8″	8″	8″	8″	8″	8″
Working depth (max.) (inches)	16″	16″	16″	16″	16″	16″	16″	16″	16″	16″	16″	16″	16″	16″	16″	16″	16″	16″	16″	16″
Tractor Power (kW)	between 90 and 120	between 112 and 149	between 112 and 149	between 112 and 149	between 112 and 149	between 134 and 179	between 134 and 179	between 134 and 179	between 134 and 179	between 134 and 179	between 157 and 209	between 157 and 209	between 157 and 209	between 157 and 209	between 157 and 209	between 179 and 239	between 179 and 239	between 179 and 239	between 179 and 239	between 201 and 268
Tractor Power (hp)	between 120 and 160	between 150 and 200	between 150 and 200	between 150 and 200	between 150 and 200	between 180 and 240	between 180 and 240	between 180 and 240	between 180 and 240	between 180 and 240	between 210 and 280	between 210 and 280	between 210 and 280	between 210 and 280	between 210 and 280	between 240 and 320	between 240 and 320	between 240 and 320	between 240 and 320	between 270 and 360

HDX142

Call for Price
